Part number (SKU) 18486900
Material Neoprene
Surface Blank
Profile H
Type 1250 H
Nominal length [in.] 125
Nominal length [mm] 3175
No. of teeth 250
Belt width 50.8 [mm]
Weight 0.27 [kg/m]

CATALOG PRODUCT PAGE

CAD FILES (download)

ADDITIONAL INFORMATION

If you need a rework or a custom-made-product please contact us directly with your inquiry.

The supplied 3D models, pictures and technical drawings are made with reasonable care.
Nevertheless liability is excluded for the accuracy and correctness of this data.

Weight 0.864 kg
Dimensions 10 × 50 × 50 cm
Material

Surface

Profile

Type

Nominal length [in.]

Nominal length [mm]

No. of teeth

Belt width

Weight

Neoprene timing belt 1250 H 250 teeth belt width 200=50.8mm PN: 18486900

Material: Neoprene with glas-fibre tensile member. Teeth surface
fabric-coated.

Timing belt with inch dimensions, classical shape with trapezoid teeth.

Profile H = 1/2" = 12.7 mm. Belt width 200 = 50.8 mm. Temperature range
-20º to +100ºC.

$126.61

Availability: 1 in stock (backorders ship within 1-2 weeks)

Quantity Discount (%) Price
1 - 9 $126.61
10 - 24 7.46 % $117.17
25 - 49 9.94 % $114.03
50+ 11.49 % $112.06

Neoprene timing belt 1250 H 250 teeth belt width 200=50.8mm PN: 18486900
