| Part number (SKU) | 33072000 |
| Material | Steel (12L13) |
| Surface | Ground finish |
| Ratio [i] | 20 : 1 |
| Module | 3 |
| No. of threads | 2 |
| Pitch Angle | 8°58 [°] |
| Outer diameter [da] | 44.5 [mm] |
| Level of efficiency | 0.63 [eta] |
| Weight | 340 [g] |
If you need a rework or a custom-made-product please contact us directly with your inquiry.
The supplied 3D models, pictures and technical drawings are made with reasonable care.Nevertheless liability is excluded for the accuracy and correctness of this data.
| Weight | 0.34 kg |
|---|---|
| Dimensions | 44 × 44 × 50 cm |
| Material | |
| Surface | |
| Ratio | |
| Module | |
| No. of threads | |
| Pitch Angle | |
| Outer diameter | |
| Level of efficiency | |
| Weight |
Precision worm centre distance 80mm i=20 PN: 33072000
Material: Steel 11SMnPb37 (1.0715), inspected for fissures, case
hardened HV 620-700, ground. Pressure angle 15°. Attention:
Keyway not according to DIN. The worms can only be used with gear wheels
having the same centre distance and the same transmission. Can be built
into gear systems, no reworking required, thus short assembly times. The
figures stated for the efficiency are only reference values, since –
besides the lead angle – also mounting, lubrication, speed and assembly
have an influence on the efficiency.
$98.05
Ships within 1-2 weeks
| Quantity | Discount (%) | Price |
|---|---|---|
| 1 - 9 | — | $98.05 |
| 10 - 24 | 1.67 % | $96.41 |
| 25+ | 3.35 % | $94.77 |
