| Part number (SKU) | 16699930 |
| Material | Stainless steel (303) |
| Surface | Blank |
| Profile | AT5 |
| No. of teeth | 30 |
| Outer diameter [De] | 46.53 [mm] |
| Toothed length [L1] | 160 [mm] |
| Total length [L] | 160 [mm] |
| Weight | 2.00 [kg] |
| optional flange [Part-No.] | 16019211 |
If you need a rework or a custom-made-product please contact us directly with your inquiry.
The supplied 3D models, pictures and technical drawings are made with reasonable care.Nevertheless liability is excluded for the accuracy and correctness of this data.
timing bar AT5 30 teeth length 160mm material 1.4305 PN: 16699930
Material: Stainless steel 1.4305 (AISI 303).
$113.53
Ships within 1-2 weeks
| Quantity | Discount (%) | Price |
|---|---|---|
| 1 - 9 | — | $113.53 |
| 10 - 24 | 2.48 % | $110.72 |
| 25 - 49 | 4.13 % | $108.84 |
| 50+ | 5.78 % | $106.97 |
