| Part number (SKU) | 17024800 |
| Material | Aluminum |
| Surface | Blank |
| Profile | HTD 3M |
| No. of teeth | 48 |
| Version | 2 |
| Belt width | 9 [mm] |
| Outer diameter pulley | 45.07 [mm] |
| Pitch circle diameter [d] | 45.84 [mm] |
| Hub diameter [ND] | 33 [mm] |
| Total length [L] | 22.2 [mm] |
| pilot hole [B] | 8 [mm] |
| Bore [max. B] | 20.0 [mm] |
| Weight | 72.0 [g] |
If you need a rework or a custom-made-product please contact us directly with your inquiry.
The supplied 3D models, pictures and technical drawings are made with reasonable care.
Nevertheless liability is excluded for the accuracy and correctness of this data.
Timing belt pulley HTD 3M material aluminium 48 teeth for belt width 9mm PN: 17024800
Material: Aluminium similar EN AW2017A. Flanges zinc-plated steel. The functionability of a belt drive is largely influenced by the quality of the used pulley. HTD pulleys are precision components, manufactured pitch-true with special cutters. This leads to a precise meshing of teeth.
$24.68
Availability: 5 in stock (backorders ship within 1-2 weeks)
| Quantity | Discount (%) | Price |
|---|---|---|
| 1 - 4 | — | $24.68 |
| 5 - 9 | 10.62 % | $22.06 |
| 10 - 24 | 21.52 % | $19.37 |
| 25 - 49 | 32.13 % | $16.75 |
| 50 - 99 | 43.03 % | $14.06 |
| 100 - 249 | 47.29 % | $13.01 |
| 250 - 499 | 51.62 % | $11.94 |
| 500+ | 53.53 % | $11.47 |
